POWER CONVERSION STATIONS

Integrated power conversion for utility-scale solar.

Module X Solutions designs, manufactures, and integrates custom power conversion skids for utility-scale solar projects. We bring inverters, transformers, and supporting electrical equipment together on concrete or steel bases, configured around each project's requirements.

THE SOLAR-TO-GRID PROCESS

  • 01 Solar Generation

    Solar panels convert sunlight to DC electricity.

  • 02 Power Conversion

    Inverters convert DC to AC and optimize output.

  • 03 Medium Voltage Integration

    Switchgear and protection equipment manage, monitor, and ensure safe, reliable power.

  • 04 Voltage Step-Up

    A transformer increases voltage to medium/high voltage for transmission.

  • 05 Grid Connection

    Clean, renewable power flows into the smart grid to power homes, businesses, and future growth.

Designed around your equipment.

Our engineering team develops skid layouts around equipment selection, electrical requirements, site conditions, and installation needs. Using 3D design tools, we coordinate component placement and cable routing before manufacturing.

Concrete and steel skid options accommodate different configurations. Equipment from multiple manufacturers can be integrated to meet the project's specifications and budget.

Integrated before delivery.

Our factory teams install and connect the equipment specified for each skid. The integration scope can include:

  • Inverters and transformers

  • DC disconnects and recombiners

  • Power cabling and control wiring

  • Controls and auxiliary equipment

Electrical testing is based on the installed equipment and project requirements. Completing this work in the factory helps reduce assembly and integration work at the site.

Support for site installation.

Skid dimensions, weight, and lifting requirements are addressed during project planning. MXS provides technical support, lifting plans, and troubleshooting to assist the installation team. Field connections, commissioning, and any additional site services are defined within the project scope.

Let’s discuss your design.

Share your concept, drawings, or project requirements. Our team will help define the engineering and manufacturing support needed to move your project forward.
